Sony and Microsoft have had a lot of work with Orbis and Durango. Create a new hardware it’s a long running process, you have to build different versions of hardware and make changes along the core until the last version, the closer one to the retail product. We have created an article with three of these machines, take note about the Orbis evolution.

Currently, there are 3 types of devkits:

1) R10 boards with special BIOS, running in generic PC’s

2) “Initial 1″ — Early devkit

model number: DVKT-KS000K
SCE-provided PC equipped with R10XX board
Runs Orbis OS
Available July 2012

3) SoC Based Devkit: early version of the ORBIS hardware

Available January 2013

Time to look inside of each devkit:

R10 Board (with special BIOS) assemble in a Generic PC

Requires Windows 7 64 bit edition
Recommend
Sandy Bridge (Intel) or Bulldozer (AMD)
Minimum 8 GB RAM (system memory)
650 Watt PSU
VS2010 SP1
DWM (Desktop Windows Manager) must be turned off
Application will use Windows services for everything except GPU interface
SCE will provide “Gnm”, a custom GPU interface

Do you remember the first Durango’s pictures? This is a very early devkit based on Windows.

DVKT-KS000K (“Initial 1″)

Runs Orbis OS
CPU: Bulldozer 8-core, 1.6 Ghz
Graphics Card: R10 with special BIOS
RAM: 8 GB (system memory)
BD Drive
HDD: 2.5 ” 160 GB
Network Controller
Custom South Bridge allows access to controller prototypes

devkits 600x375 ORBIS Devkits Roadmap/Types

DVKT-KS000K

SoC Based Devkit

Available January 2013
CPU: 8-core Jaguar
GPU: Liverpool GPU
RAM: unified 8 GB for devkit (4 GB for the retail console)
Subsystem: HDD, Network Controller, BD Drive, Bluetooth Controller, WLAN and HDMI (up to 1980×1080@3D)
Analog Outputs: Audio, Composite Video
Connection to Host: USB 3.0 (targeting over 200 MB/s),
ORBIS Dualshock
Dual Camera

The last devkit is the closer one to the retail console. Expect a machine with these specs or similar to these ones. Obviously, Sony could introduce changes in these features, but don’t expect deep mods.
